Description
The Petzl Rollclip Triact-Lock Pulley Carabiner is designed to minimize friction on your work rope or to install redirects. The keylock system prevents accidental snagging when putting the pulley in place and the gate opening on the pulley side makes it easy to install rope when the pulley is fixed to an anchor. The sheave is mounted on sealed ball bearings for excellent efficiency.
Details
Material: Aluminum
Min. Rope Diameter: 7mm
Max. Rope Diameter: 13mm
Sheave Diameter: 18mm
Max. Working Load: 2 x 2 = 4kN
Efficiency: 85%
Major Axis Strength: 20kN
Minor Axis Strength: 8kN
Open Gate Strength:7kN
Gate Opening: 22mm
- Sealed ball bearings
- May be used with a CAPTIV positioning bar
- H-Profile ensures improved strength-to-weight ratio
- Certifications:
- CE EN 362, CE EN 12278, EAC
- Color:
- Gold
- Gate Opening:
- 7/8 in (22 mm)
- Material:
- Aluminum
- Rope Capacity:
- 1/2 in (13 mm)
- Tensile Strength:
- 4,496 lbs (20kN)
- WLL:
- 899.2 lbs (4 kN)
- Country of Manufacture:
- FR
- Manufacturer Part Number:
- P74 TL
- Product Type:
- Auto Locking
- NFPA Certified:
- No
